Hydrogen Cyanide gas detection in Jewelry Industries

Jewelry manufacturers are increasingly worried about their worker’s health and safety conditions, Most jewelry companies want to prevent work-related illness and injury, and they also want to prevent pollution from their manufacturing processes, we have Smart Gas Detectors for Jewelry Manufacturing & Polishing Industries.

Most of the gases/solvent acid used or generate during the Jewelry polishing, Soldering, Dewaxing,  process are like Cyanide, Hydrogen Cyanide, Hydrofluoric acid  Sulphur dioxide , Nitric Oxide, Hydrochloride, Methyl Chloride, Cadmium, Acetone, Hydrogen, Methane, these gases are highly toxic and life threatening to avoid any unwanted accident the management need to install Smart MSR Germany Hydrogen Cyanide (HCN) Gas Detector, Sensor uses latest  Electrochemical Diffusion type Sensing Technology  to detect the Hydrogen Cyanide (HCN) with High accuracy in less time (Highly Responsive).

The 12bit Microprocessor Converter ensures the highest accuracy, sensitivity, selectivity and reliability despite the long calibration interval.

Click Here to see the On site demonstration video, Hydrogen Cyanide Gas Detection and Control Monitoring system installed at one of the gold design manufacturing Plant.

These gases or it’s vapor are very dangerous for human health, may cause Lungs cancer, Blood Cancer, Kidney, Liver damage, Cyanide gases are very dangerous for human life sometimes cause instant death.

Since it comes under critical Human Life Safety, it is very important to Install authenticated, Gas Detection and Control Monitoring systems in the areas where these dangerous gases or solvent are used, so that it can be monitor, control & provide safe area to Work, definitely it will increase your productivity too when your worker do their work with secure mind.

We can help you in all your safety automation, gas detection needs, please feel free to contact us anytime at INFO@ALVIAUTOMATION.COM +91-7091777274

Introducing the FISCHER Germany FT90: Your go-to solution for precise measurement

🚀 Elevate your precision and efficiency with FISCHER Germany FT90! 🌡️📊 This device is your ultimate companion for measuring humidity, temperature, pressure, and more in neutral gaseous media.

🌐 Applications:

• Humidity & and temperature measurement
• Cleanroom monitoring
• Air intake/exhaust systems
• Filter monitoring
• Volume flow measurement
• Process monitoring

💡 Key Features:

• Robust & and maintenance-free design
• Simple configuration for hassle-free operation
• Humidity & temperature: 0 to 100 %rH, -40 to +100 °C
• Optional differential pressure measurement: 25 Pa to 25 kPa
• Turn down ratio of 4:1 for flexibility
• 4 configurable switch outputs for seamless control
• Multi-line LC display with color backlighting for intuitive visualization
• Digital interfaces: USB OTG, RS485 Modbus RTU

🔥 Safety First:

• Gas Explosion Protection: II 3G Ex ec IIC T4 Gc
• Dust Explosion Protection: II 3D Ex tc IIIB T125°C Dc
• Operating Temperature: -20°C ≤ Tamb ≤ 60°C

Upgrade your monitoring system today! 🌐💼

📩 Reach out to us at  info@alviautomation.com 🌐 or give us a call at +91 7091777274 / +91-9471515909 📞 for more information! We’re here to help!

#IndustrialMonitoring #FT90 #EfficiencyInTech #PrecisionMeasurement #FISCHERGermany #TechInnovation 🔍🔬

Digital Differential Pressure Transmitter

The Fischer Germany DE90 is a Digital Differential Pressure Transmitter with additional switch outputs. It is suitable for measuring overpressure, under-pressure and differential pressure in neutral gaseous media & also the replacement of DE45 model.
The device may only be used for the purpose stipulated by the manufacturer.

Multifunctional differential pressure transmitter for air and neutral gases, optionally applicable in ATEX zones 2 and 22, large LC-display with colour change indicator. The digital differential pressure transmitter is suitable for many applications and is used in dynamic filter monitoring. The flexible device concept for your industrial applications.

Typical applications
• Space and clean room monitoring
• Supply and exhaust air systems, TNV systems
• Dynamic filter monitoring
• Filter monitoring
• Flow rate measurement
• Surface coating systems
• Process monitoring

Important features
• Robust, resistant to overpressure and maintenance-free
• Simple configuration
• Measuring ranges from
25 Pa to 25 kPa, – 1 mbar to 250 mbar
• Measuring accuracy up to 0.5%
• Turn Down 4:1
• Optionally one or two-channel mode with
Configurable output signal 0/4 … 20 mA, 0/2 … 10 V or 1…5V
Characteristic curve implementation and adjustment to the process 1 to 4 configurable switching outputs
• Multi-line LC display Full graphic, colour backlighting for visualising the operating states,  Multilingual plain text menu
• Digital interfaces  USB OTG,  RS485 Modbus RTU

For more details and product enquiry please get in touch with us at Info@alviautomation.com

For The Technical Datasheet please click here

DE16 Fischer Differential Pressure Transmitter

DE16 Fischer Differential Pressure Transmitter

Make – Fischer Germany

Model : DE1602VDYYB90K00D0579 (in accordance with article DE1602VDYYB9D128)

Application:

DE16 Fischer Differential Pressure Transmitter can be used in different measuring range and application area like:-

Measuring transmitter for overpressure, partial vacuum and differential pressure.
This series is suitable for various measuring applications in the field of industrial and sanitary techniques.

Measurement of differential pressure between forward- and return flow
in heating systems. Monitoring of filters, blowers and compressors.

Main Features

• Overpressure protection
• Rugged design
• Maintenance and wear free inductive pick-up
• Multiple applications
• Measuring range 0-1 bar (also available in diffrent measuring range, refer to the datasheets)
• Measuring diaphragm/gaskets Viton Pressure chamber Aluminium/HART COAT Output Signal 4-20 mA 2-wire
• Power supply 24V DC ±10% Electrical connection cable terminal box Suitable for connection to Siemens/Fender flange
• Protection class: IP65 Outputsignal limited to 20 mA
• Tolerance range for current limiting Toleranzbereich fur die Strombegrenzung
• O-Ringe im Verschlussbeutel dem Gerat beigelegt Sprache (Typenschild): deutsch Typenschild: mit Fischer Logo Kennzeichnung: mit CE und UKC
  Betriebsanleitung: ohne BA

  Many more features refer to the attached DE 16 Datasheet

Fischer Pressure Temperature Humidity Measuring Instruments

DE 90 Digital Differential Pressure Transmitter

DE90 model of Fischer Germany Multifunctional Fischer Pressure Temperature Humidity Measuring Instruments for air and neutral gases.

Optionally applicable in ATEX zones 2 and 22, large LC-display with colour change indicator. The digital differential pressure transmitter is suitable for many applications and is used in dynamic filter monitoring.

The flexible device concept for your industrial applications

The FISCHER ECO-LINE – The new Differential-Pressure Transmitter DE80.

The differential pressure transmitter from the FISCHER ECO-LINE® is robust, safe against overpressure, maintenance-free and suitable for neutral gas media. Typical areas of application are technical building equipment, clean room technology, filter monitoring, volume flow measurement, the control of frequency inverters, the measurement and monitoring of overpressure, negative pressure and differential pressure.

The measuring ranges for this differential pressure transmitter are between 25 Pa and 25 kPa or 0.25 mbar to 250 mbar. A possible offset correction can be made via a zero point button in the DE80 . Each basic measuring range can be spread into seven predefined measuring ranges via a DIP switch. In the basic measuring range, the maximum measuring error (linearity, hysteresis and non-repeatability) is 1.5%.

In addition to the switchable analogue output 0/4 … 20 mA or 0/2 … 10 V, the 3-wire version has an optional fully graphic LC display and an optional changeover contact. The 2-wire version has a current loop 4 … 20 mA and optionally a fully graphic LC display. The Modbus RTU version has an optional full-graphic LC display.

Fischer Pressure Temperature Humidity Measuring Instruments DE16, DE45, DE46, DS11, ME11, ME13 MA13, MA11, MA30, MS11, TW39, TW36  & many other related series are specially designed  robust, safe against overpressure, maintenance-free and suitable for Neutral gas, Air,  Vacuumed pressure media. For more details and enquiries please get in touch with us on   Info@alviautomation.com

Also you can visit us at  Indiamart

Fixed Gas Detection Systems for Petrochemical Industry

It is mandatory norms to use Fixed Gas Detection Systems for Petrochemical Industry for  Safe protection against CH4 / C5H12 / C3H8 / H2S / O2 / CO / NH3/H2/LPG gas leakage.

We do recommend Plant manager, EHS, and maintenance department install quality  sensor transmitters in their plant because it is a matter of critical life and plant safety.

In the chemical and petrochemical industry, permanent monitoring of rooms and plants in which explosive or toxic atmospheres can form is required.

Personal protection requires the monitoring of hazardous gases in accessible areas, on the one hand to prevent accidents, thus guarantee the health and safety of employees & Plant.

In addition, MSR Electronic offers solutions of Fixed Gas Detection & control monitoring Systems for Petrochemical Industry for the protection of your plant against such unwanted gas leakage accident and the financial loss.

Furthermore, process safety can be further optimized with quality gas detectors from MSR-Electronic.

Our Fixed Gas Detection Systems for Petrochemical Industry have following key features and approvals which enhance our product demands in the world’s petrochemical industries :

• • Continuous self-monitoring• Microprocessor with 12-bit converter resolution
• • ATEX and IECEx certificates MSR-Electronic for electrical Ex protection
  • Approved Measuring Function for the Explosion Protection
  • SIL2 safety functions 4–20 mA, RS-485 and relay
  • MED Certificate and TA Certificate: Approval according to Marine       Equipment Directive 2014/90/EU by DNV
  • Enclosure: additional FM and CSA certificates for Class I, Div. 1
  • Calibration service by exchanging the sensor head
  • Alarm and fault signal relay
  • LCD display with status LEDs (optional)
  • IP66 protection with SplashGuard accessories (optional, see data sheet Accessories)

Thus we recommend/ request #IOCL, #BPCL #HPCL #RPL #GAIL #Haldia #Manali #DCW #Savita #thinkgas petrochemical authorities to consider quality Fixed Gas Detection & Control monitoring Systems for their Petrochemical Industry in India too.

For more details ad inquiries please feel free to contact us at Info@alviautomation.com  or also visit us on  Indiamart

Differential Pressure Transmitter

The differential pressure transmitters of the 984 series are used to measure differential pressure, overpressure, and vacuum. They provide up to 8 pressure ranges and 2 output signals, which are easily selectable by a jumper or rotary selector switch.
#savemoney #SaveEnergy #Healthlife #Greenhousegases #Beck #germany #DifferentialPressureTransmitter #DPT #DPS #DifferentialPressureSwitch for #BuildingAutomation and #airconditioning #Overpressuremeasurement in #cleanrooms and #laboratories #HVAC #Special #discounted #price #available.
ALVI Automation – GasAlarm India
For more technical details and price please contact us anytime at Info@alviautomation.com. or call at 7014396625|7091777274.

Hydrogen Cyanide (HCN) Gas Detection Systems

Hydrogen Cyanide gas is highly dangerous and life-threatening, It is important to install high quality HCN Gas Detection and Control Monitoring Systems in the area where is the possibilities of HCN Gas leak or presence.

Hydrogen Cyanide (HCN) Gas Detector (developed by MSR Germany ) is the new exchangeable, world’s most compact and miniaturized sensor that is capable of digital value processing, temperature compensation, and self-control for the continuous monitoring of the ambient air to detect Hydrogen Cyanide (HCN) Toxic gas in the environment where these gases are use or generate to avoid any hazardous incident and painful loss, and provide a secure & safe environment leads to increase your daily productivity.

Click Here to see the On site demonstration video, Hydrogen Cyanide Gas Detection and Control Monitoring system installed at one of the gold design manufacturing Plant.

We have Smart MSR Germany Hydrogen Cyanide (HCN) Gas Detector, Sensor uses latest  Electrochemical Diffusion type Sensing Technology  to detect the Hydrogen Cyanide (HCN) with High accuracy in less time (Highly Responsive).

The 12bit Microprocessor Converter ensures the highest accuracy, sensitivity, selectivity and reliability despite the long calibration interval.

For more details and enquires please contact us – INFO@ALVIAUTOMATION.COM also you can visit us in IndiaMart Site

Gas Detectors for Jewellery Manufacturing & Polishing Industries.

Jewellery manufacturers are increasingly worried about their worker’s health and safety conditions, Most jewellery companies want to prevent work-related illness and injury, and they also want to prevent pollution from their manufacturing processes, we have Smart Gas Detectors for Jewellery Manufacturing & Polishing Industries.

Most of the gases/solvent acid used or generate during the Jewellery polishing, Soldering, Dewaxing,  process are like Cyanide, Hydrogen Cyanide, Hydrofluoric acid  Sulphur dioxide , Nitric Oxide, Hydrochloride, Methyl Chloride, Cadmium, Acetone, Hydrogen Methane.

These gases or it’s vapour are very dangerous for human health, may cause Lungs cancer, Blood Cancer, Kidney, Liver damage, Cyanide gases are very dangerous for human life sometimes cause instant death.

Since it comes under critical Human Life Safety, it is very important to Install authenticated, Gas Detection and Control Monitoring systems in the areas where these dangerous gases or solvent are used, so that it can be monitor, control & provide safe area to Work, definitely it will increase your productivity too when your worker do their work with secure mind.

We can help you in all your safety automation, gas detection needs, please feel free to contact us anytime at INFO@ALVIAUTOMATION.COM +91-7091777274

Make Tomorrow Safer Than Today Using Our Cutting Edge Revolutionary Enhance Gas Radicals VEFSA – Very Early Fire and Smoke Alarm With German Technology and Australasian Expertise

We ALVI Automation (India) Pvt. ltd. is specialized in Fixed, Transportable Gas Detection and monitoring alarm system. ALVI Group and Gas Alarm Systems are involved in designing, engineering, implementing, and calibrating Gas Detection and Alarm systems, Instrumentation, and process analytics.

Click Here to Download Company Catalogue

We ALVI Automation feel pleased to introduce our best reliable, Precisely & selectively designed engineered product VEFSA (Very Early Fire & Smoke Alarm System) which is capable of detecting very early enhanced gas radicals (The first sign to be measured before the fire takes place.)

We already know that there are 5 stages of fire (as shown in the diagram)

• 1^st stage: Generation of Gas Radicals Incipient Stage
• 2^nd stage: non-Visible smoke Smouldering Stage I
• 3^rd stage: Visible smoke Smouldering Stage II
• 4^th stage: Flame Stage
• 5^th stage: Heat Stage

But at present, all the conventional fire alarm systems & fire extinguishing systems activate when 50-60% of damage has been already occurred because of their limitations.

Continue reading “Make Tomorrow Safer Than Today Using Our Cutting Edge Revolutionary Enhance Gas Radicals VEFSA – Very Early Fire and Smoke Alarm With German Technology and Australasian Expertise”

VEFSA – Carbon Monoxide Sensor Transmitter

Enhanced CO gas radicals detection by VEFSA – Carbon Monoxide Sensor Transmitter for  Very Early Fire Smoke Alarm Systems very useful for CO  Car Park Monitoring /Ventilation Fan control, also meeting following standards:

• AS 1668.2 mechanicalVentilation
• Pollution & Emission Control
• Green House Gas Saving
• Also, save Energy for Next Generation
• Very Eary Fire & Smoke Alarm
• Useful for the protection of Human life Building, Basement, Plant, Industries.

Our Gas-CO-300-D CO Gas Detector/Sensor Transmitters  is capable to detect and measure CO, Smoke & CO+ Enhanced Gas radicals (Fumes before the fire smoke begins)

Gas CO, Carbon Monoxide Sensor Transmitter comes with typical measuring range of 0-100ppm, 0-300ppm, 0-500ppm, having gel-type Electrochemical sensor cell (without any orientation problem), GAS-CO-300-D Sensor Transmitter is a highly responsive,  high accuracy, fast repeatability & high-reliability, user friendly, easy to use model.

Gas-CO-300-D model  VEFSA Carbon Monoxide Sensor Transmitter has a coverage area of 465 Sqm to 936Sqm.

Gas-CO-300-D model VEFSA CO Sensor Transmitter gives analog output 4-20mA or 2-10V, need supply power of 24VDC.

For more details and enquiry please feel free to contact us anytime at – Info@alviautomation.com

Joventa Germany – Electric Motorized Damper Actuator

Electric Motorized, Damper Actuator, Electric Fire Damper Actuator play major roles in #hvacsystem, Actuator ensures the proper automatic functions of the Damper in Ventilation Systems.
We have the electric actuators of the #JOVENTA #Frakta make, of measuring range 2 Nm to 32 Nm Torque, Actuators have been developed for adjusting small to Large air flaps in ventilation and air conditioning units.
The compact design and universal adapter fitted with the limitation of rotation, angle, running time, easy to use and no maintenance cost make this JOVENTA actuator highly versatile.

#Small / #Silence  #Standard #8Nm / #16Nm #24Nm #32Nm
#Special #MixerDrive  #SpringBack #SpringReturn #dampers #Motorized #Electric #FireDamper #Actuator #ventilationsystem #Poweplant #automation #design

Ethyl Alcohol – Ethanol Sensor Transmitter

We know how to solve your Ethyl Alcohol – Ethanol Sensor Transmitter gas detection problem! And, we make it easy for you here at Alvi Automation India Gas Alarm Systems for protection from Ethyl Alcohol, Ethanol, Methanol, Alcohol used as a key ingredient in the manufacturing of Hand sanitizer, Nail Remover, Nail paint,  spirit, thinner, alcohol, wine & we ALVI   Automation India can help, assist, you in design engineering, consultancy, and implement of our world-class German Ethanol gas detection system for all storage area, processing, and manufacturing units for critical life safety and asset protection.

Fixed PolyXeta 2 Gas Alarm Devices of the

1. PX2-1 series with Ex db protection for Zone 1 and 2
2. PX2-2 series with Ex nA protection only for Zone 2

Designed for the continuous monitoring of the ambient air to detect combustible gases and vapors for use in the hazardous areas of zones 1 and/or 2 according to Directive 2014/34/EU.

Application:

The PolyXeta®2 sensor is used in industrial areas like the oil/gas industry, biogas plants, petrochemical industry, power plants etc. in Ex-Zone 1 (PX2-1) and/or 2 (PX2-2). The PolyXeta®2 sensor is also suitable for commercial areas like gas transfer stations etc.

With the 4–20 mA / RS485-ModBus output signal, the sensor is suitable for connection to the PolyGard®2 gas controller series by MSR-Electronic, as well as to any other controllers or automation devices. Optionally, the PolyXeta®2 sensor is also available with LCD display and relay output.

FEATURES:

ATEX and IEC Ex certificates MSR-Electronic for electrical Ex protection
• Metrological test & SIL2 safety functions 4–20 mA, RS485, and relay
• PX2-1 for zone 1 (and also suitable for zone 2):
• Type “Ex db” with flame-proof enclosure
• PX2-2 for zone 2:
• Type “Ex nA” with flame-proof enclosure
• Enclosure: additional CSA certificate for Class I, Div. 1
• Continuous monitoring
• Microprocessor with 12-bit converter resolution
• Self-monitoring system
• Easy calibration
• Calibration service by exchanging the sensor head
• Proportional 4–20 mA output
• Serial interface to the control center
• Reverse polarity protection
• Overload protection
• LCD display with status LEDs (optional)
• Alarm and fault signal relay (optional)

Toxic Combustible Refrigerant Fixed Gas Detection Systems

German Technology and German quality is the best in the World, we are pleased to introduce that we too offering the best German technology for Fixed  Gas Detection systems & Instrumentation Solutions for critical life safety and assets protection and enhancement from all types of Toxic (CO, CO2, Ethylene, Oxygen, Ammonia, CL2, NO2, O3, So2, H2S, HCN Gas )  Combustible (H2, LPG, Petrol Diesel Vapor, Methane, Methyl Ethyl Ketone, Propane, Acetone Methanol Gas) Refrigerant (R134a, R410a, R32, R434a,  R123, R22, etc.. Gas) gas leakage.

 Fixed Gas Detection systems provide continuous monitoring to the facilities and alert the responsible person immediately to prevent any hazardous incident.

A permanent gas detector enhances workplace safety and prevents loss of productivity due to leakage or accidents.

For more Details Please feel free to contact us anytime  – Info@alviautomation.com

Carbon Monoxide (CO) Detector for Basement Car Parking

When it comes to Carbon Monoxide (CO) Detector for Basement Car Parking to control & operate the Jet, Fresh air, Exhaust automatically  MSR Germany/GASAlarm make  Compact GAS-CO-300-D model is the Best techno-commercial option in the International HVAC market, having following features.

SPECIFICATIONS:-

• Sensor Model Available in Stock: – GAS-CO-300-D
• Measuring Gas: Carbon Monoxide, Enhanced CO + radicals Detection.
•  Sensor element (cell):- Electrochemical Diffusion, Electrolyte type Gel-based (no leak, no membrane rapture, no orientation problem & no false alarm)
•  Measuring Range: – 0-300 ppm (Standard)
• Connection: – Two and Three-wire sensor
• Response time T90:-  ≤ 30 Sec
• Warm-up time (First Time):- ≤ 3 Min.
• Protection Class Available in: IP65 (Flameproof and weatherproof )
• Stability & resolution: – ± 3 ppm
• Sensor life expectancy:- ≥ 6 years (Site Feedback ≥ 12 Years )
• Calibration Interval: 1 Year.
• Sensor Coverage Area: – 700 m² to 935m², ideal condition.
• Humidity non-condensing : 15-90% RH
• Working temperature:–10°C to 50°C
• Power supply:-  18 – 28 VDC ( Overload protected)
• Analog output signal:- Standard: 4-20 mA Linear Output, also available in 2-10VDC
• Flammability: – UL 94: V2
• Warranty: 12 Month only on manufacturing defects
• Guidelines Approval:  CE/ UL Enclosure.

For More details & enquiry please contact – Info@alviautomation.com
